32 ft ECOlink Meeting Room Cabin – Stackable, Linkable, Double Glazed Windows

The ECOlink meeting room cabin is a 32 ft portable building constructed with a flat sided exterior finish. The unit is designed for use on larger sites requiring project accommodation and meeting space.

The cabin is stackable and can be linked side by side with other ECOlink offices, meeting rooms, canteens, kitchens, and drying rooms. This allows the creation of mixed-use accommodation blocks and well-connected project facilities.

Energy saving features include PIR (passive infrared) sensors for lighting and timers on heating systems. The windows are uPVC double glazed. Double glazing consists of two glass layers with an air gap between them, which reduces heat transfer and exterior noise.

Air source heating and cooling is available as an optional extra.

Technical Specifications

External Dimensions:

• Length: 9.76 m (approximately 32 ft)

• Width: 3.0 m (approximately 9.8 ft)

• Height: 2.7 m (approximately 8.9 ft)

Internal Dimensions:

• Length: 9.51 m

• Width: 2.75 m

• Height: 2.3 m

Door:

• Width: 0.8 m

• Height: 1.99 m

Windows:

• Quantity: 4

• Type: uPVC double glazed

Construction:

• Exterior finish: Flat sided

• Flooring: 18mm particle board

Electrical & Heating:

• Lighting control: PIR sensors

• Heating: Timed system

• Optional climate control: Air source heating and cooling

Compatibility and Intended Use

This ECOlink meeting room cabin is intended for ground-level placement on flat, load-bearing surfaces or for stacking with compatible units. Typical applications include:

• Project office and meeting space on larger sites

• House building and infrastructure project sites

• Mixed-use accommodation blocks (when combined with canteens, kitchens, and drying rooms)

• High-profile or flagship project sites

The unit can be linked side by side or stacked with other ECOlink units in the range.

Package Includes

• 32 ft ECOlink meeting room cabin

• Flat sided exterior finish

• PIR sensors for lighting

• Timed heating system

• 4 x uPVC double glazed windows

• 18mm particle board flooring

Optional air source heating and cooling is not included unless specified at time of order.
