40 ft Full Side Access Container – High Cube, Corten Steel, CSC Plated_

This 40 ft full side access container is configured as a high cube unit, providing additional interior height compared to standard containers.

The container features a full side opening measuring 11,836 mm (38 ft 9 in) with no central post, allowing unobstructed access along the entire side.

The container is constructed from Corten steel. Corten steel is a weathering steel that forms a protective rust layer when exposed to the elements, reducing long-term corrosion.

The container includes CSC plating with a maximum gross weight of 24,000 kg.

Exterior hinged double doors are located at one 8 ft end, with two locking bars per door. Double doors are located on one 40 ft side, with three locking bars per door.

The flooring is 28mm marine plywood installed on steel cross members. Marine plywood is manufactured with water-resistant adhesives and resists delamination in humid conditions.

Eight vents are installed for airflow. A steel bunded floor can be installed at an additional cost.

Technical Specifications

External Dimensions:

• Length: 12.19 m (approximately 40 ft)

• Width: 2.44 m (approximately 8 ft)

• Height: 2.90 m (approximately 9 ft 6 in – High Cube)

Internal Dimensions:

• Length: 12.03 m

• Width: 2.29 m

• Height: 2.70 m

Doors:

• End door width: 2.23 m

• End door height: 2.59 m

• Side door width: 11.84 m (38 ft 9 in)

• Side opening: No central post

Weight:

• Tare weight: 6,200 kg (approximately 13,669 lbs)

Construction:

• Material: Corten steel

• CSC plate: Yes, max gross weight 24,000 kg

• End door locking bars: 2 per door

• Side door locking bars: 3 per door

• Flooring: 28mm marine plywood on steel cross members

• Vents: 8

• Optional floor: Steel bunded floor (additional cost)

Compatibility and Intended Use

This full side access container is intended for ground-level placement on flat, load-bearing surfaces or for transport via flatbed truck. Typical applications include:

• Side loading and unloading of cargo

• Storage requiring access from the side

• Retail or display applications

• Workshop or workspace conversion

The full side access design allows loading and unloading along the entire length of the container without obstructions.

Package Includes

• 40 ft full side access container

• High cube configuration

• Corten steel construction

• CSC plate

• Exterior hinged double doors (end)

• Double doors (full side, 11,836 mm opening)

• Two locking bars on end doors

• Three locking bars on side doors

• 28mm marine plywood floor on steel cross members

• Eight vents

Steel bunded floor is not included unless specified at time of order.
