This 20ft shipping container is modified specifically for beverage service applications. The container begins as a standard ISO-certified unit and undergoes modification including serving hatch installation, interior fit-out, and electrical installation.
A serving hatch is installed on one sidewall measuring approximately 6ft in width by 3ft in height. The hatch includes a retractable window and a fold-down exterior shelf. The interior side includes a bar counter surface mounted at standard serving height.
The interior includes lockable storage cabinets positioned below the bar counter. Additional overhead shelving is installed for glassware and supplies. The floor is covered with commercial-grade vinyl sheeting over the existing marine-grade plywood subfloor.
The electrical system includes a 4-circuit sub-panel rated for 120V AC, four duplex receptacles, two overhead LED light fixtures, two under-counter LED strip lights, and an exterior weatherproof inlet box for connection to a generator or site power. Wiring is routed through conduit.
The original cargo doors at one end remain fully operational, measuring 7ft 5in in width by 7ft 3in in height. Door locking bars operate with a standard locking mechanism.
The container body is constructed from 14-gauge Corten steel. All cut edges and weld points are finished with rust-inhibiting coating. The exterior may be finished with a branded wrap or industrial coating as specified at the time of order.
Technical Specifications
- Container Type: ISO standard, Corten steel, modified
- External Length: 20ft
- External Width: 8ft
- External Height: 8ft 6in
- Internal Length: approximately 19ft 4in
- Internal Width: 7ft 8in
- Internal Height: 7ft 9in
- Serving Hatch Width: 6ft
- Serving Hatch Height: 3ft
- Serving Hatch Features: Retractable window, fold-down exterior shelf
- Bar Counter: Interior mounted, standard serving height
- Storage: Lockable cabinets, overhead shelving
- Flooring: Commercial-grade vinyl
- Electrical System: 120V AC, 30 amp max input, 4-circuit sub-panel, 4 outlets, 2 overhead LED lights, 2 under-counter LED lights
- Cargo Door Opening Width: 7ft 5in
- Cargo Door Opening Height: 7ft 3in
- Tare Weight: approximately 6,200 lbs
- Steel Gauge: 14-gauge corrugated sidewalls
- Forklift Pockets: 4 (end base locations)
Intended Use
Suitable for mobile beverage service, event catering, festival concessions, pop-up bars, or permanent outdoor hospitality installations. Designed for placement on compacted gravel, concrete pad, or level ground. Electrical system requires connection to an external power source by a licensed electrician. Plumbing and refrigeration systems are not included unless specified at the time of order. The purchaser is responsible for verifying local health department requirements and obtaining necessary permits for food or beverage service. Not certified for residential habitation or medical use.
Package Includes
- One modified 20ft shipping container
- One side serving hatch with retractable window and fold-down shelf
- Interior bar counter surface
- Lockable storage cabinets and overhead shelving
- Commercial-grade vinyl flooring
- Pre-installed electrical sub-panel with outlets and lights
- Exterior weatherproof power inlet box
- One pair of cargo doors with locking bars
